8 Channel Cwdm Different Types Of Fwdm Dwdm Cwdm Coarse Wavelength Division Multiplexer

Name: 8 Channel Cwdm Different Types Of Fwdm Dwdm Cwdm Coarse Wavelength Division Multiplexer
Brand: Gezhi or OEM
Price: 1 USD

China 8 Channel Cwdm Different Types Of Fwdm Dwdm Cwdm Coarse Wavelength Division Multiplexer wholesale

Brand Name : Gezhi or OEM

Model Number : 8CH cwdm module AA

Certification : CE RoHS,ISO9001

Place of Origin : China

MOQ : 1 pieces

Price : USD >= 1 pieces $20

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000 Piece/Pieces per Day

Delivery Time : 7 Days

Packaging Details : inner box,Carton

Model : 8CH cwdm module

Return Loss : ≥45

Operating temperature : 0 ~ +70 or -40 ~ +85

Application : CATV Links

Operating Wavelength : 1260-1620

Operating Number : 8+1

Network : TCP, POE, GPRS, wifi

Contact Now

Product description

8 CH Coarse WDM Mux Demux Module different types of Fwdm Dwdm Cwdm

GEZHI's 8 CH Coarse WDM Mux Demux Module 1470~1610 + wide 1310nm is ABS module with SC/APC pigtailed. This 8 CH Coarse WDM Mux Demux Module 1470~1610 + wide 1310nm can solve the shortage of fiber and transparent transmi-ssion of business, and reduce the cost of network building. With low-cost, low power consumption and small com-pact, it is widely used in access layer and metro aggregation to do transmission on a short time.

8 Channel Cwdm Different Types Of Fwdm Dwdm Cwdm Coarse Wavelength Division Multiplexer

Features:

Low Insertion Loss
High Isolation
Low PDL
Compact Design
Good Channel-to-Channel Uniformity
Wide Operating Wavelength:From 1260nm to 1620nm
Operating Temperature: From -40°C to 85°C
High Reliability and Stability

8Channle CCWDM Single Fiber Mux (Compact Coarse Wavelength Division Multiplexer)

Parameter		8CH Mux or Demux
Center Wavelength (nm)		ITU, ITU+1
Passband (nm)		ITU±6.5
Operating Wavelength (nm)		1470~1610nm + Wide 1310nm
Channel Space (nm)		20
Fiber Type		SMF-28e or customer specified
IL (dB)		<2.8dB
Isolation(dB)	Adjacent Channel	30
	Non-Adjacent Channel	45
PDL (dB)		0.2
PMD (ps)		0.1
Return Loss (dB)		45
Directivity (dB)		50
Maximum Optical Power (mw)		500
Operating Temperature (℃)		-20~+70
Storage Temperature (℃)		-40～85
Connector		SC/APC
BOX Package (mm)		ABS box 100x80x10

Our Certificate

8 Channel Cwdm Different Types Of Fwdm Dwdm Cwdm Coarse Wavelength Division Multiplexer

Test Enviroment

NO-dust workshop

High Temp. Ageing & High-Low Temperature cycling

100% Testing Before Shipment

Optical Spectrum Analysis
